Poly Crystalline

Smart Energy for a Sustainable Future

Efficient Polycrystalline Technology

Polycrystalline solar panels are a reliable and budget-friendly option for harnessing solar energy. Made from multiple silicon crystals, these panels offer a high level of efficiency while maintaining affordability, making them ideal for residential, commercial, and industrial applications. Their durable design ensures long-term performance, even in harsh weather conditions.
With advancements in solar technology, polycrystalline panels now provide improved energy output, making them a sustainable choice for those looking to reduce electricity costs and lower their carbon footprint. Whether for rooftop installations or large-scale solar farms, polycrystalline panels deliver consistent and eco-friendly power, contributing to a greener and more energy-efficient future
=
High Energy Efficiency
=
Cost-Effective
=
Durable & Long-Lasting
=
Eco-Friendly Solution
=
Versatile Applications

Specifications

No. Of Cells 72 Cells - 5BB
Voltage 24 V
Maximum System Voltage 1000/1500 V DC
Module Efficiency 17.40%
Dimension (LxWxH) 1960x990x35/40 mm
Weight 20.5 Kg
Maximum Series Fuse Ratings 30A
Power Output Range 330W - 350W
Operating Temperature -40°C to +85°C
Temperature Coefficient of Power (Pmax) -0.41%/°C
Temperature Coefficient of Voltage (Voc) -0.31%/°C
Temperature Coefficient of Current (Isc) +0.05%/°C
Frame Material Anodized Aluminium Alloy
Junction Box IP67/IP68 Rated with Bypass Diodes
Cable Length 1200 mm
Connector Type MC4 Compatible
